TEISON EV Charger pro business Ocpp PRE ORDER

Specification

Model

TS-EVC07-002C-001

AC Nominal Input

Phase

1 or 3 phase+neutral+PE

Voltage

230V±10%

Frequency

50Hz

AC Nominal Output

Voltage

230V±10%

Current

32A

Power

7KW

Structure Design

Housing Material

PC+PBT

Front Panel

Temper glass

Installation Method

Wall-mount/Floor-stand

Charging Outlet

One charging cable （Type 1/Type 2）

LED Indicator

Green/yellow/red/blue for different status

LCD Display

Display charging data

Emergency Stop Button

Yes

RFID Function

2pcs cards

Environmental Index

Protection Level

IP67 for Box

Temperature/Humidity

-30~50°C/5%~95% without condensation

Working Altitude

＜2000M

Application Site

Indoor/Outdoor

Security Protection

Multiple Protection

Over current, Under voltage, Over voltage, Residual current, Surge protection,
Short circuit,Over temperature, Ground fault,Current leakage protection

Safety Standard

EN 61851-1

MTBF

100000 Hours

Warranty

2years

Package Information

Product Dimension

398x324x120mm

Package size

580x440*320mm

Net weight

10KG

Gross weight

12.5KG

External packing

Carton

Optional Parts

Network Gateway

Ethernet/Wifi/4G communication

Communication Protocol

OCPP1.6 (J-SON) or ( SOAP)

RCD

TYPE B

Energy Meter

MID certified
